| 链 号 | 节距 | 滚子 | 链板 | 翼片 | 翼片 | K型系列 | H型系列 | 破断载荷 | ||||||
| p | d | T | L | k | f | w | h6 | d4 | c | c1 | f | D7 | daN | |
| C208AS C208AL |
25.4 | 7.95 15.88 |
1.5 | 9.5 | 19.1 | 25.4 | 39.6 | 9.1 | 3.4 | 13.5 | 11.1 | 20.5 | 5.5 | 1380 |
| C208BS C208BL |
25.4 | 8.51 15.88 |
1.6 | 12.7 | 25.4 | 39.6 | 9.1 | 4.5 | 13.5 | 11.1 | 20.5 | 5.5 | 1783 | |
| C2108AS C210AL |
31.75 | 10.16 19.05 |
2 | 11.9 | 23.8 | 31.8 | 49 | 11.1 | 5.3 | 15.9 | 14.3 | 25 | 6.6 | 2180 |
| C212AS C212AL |
38.1 | 11.91 22.23 |
2.4 | 14.3 | 28.6 | 42.9 | 67.8 | 14.7 | 5.5 | 19.1 | 17.5 | 32.9 | 9.2 | 3110 |
| C218AS C216AL |
50.8 | 15.88 28.58 |
3.2 | 19.1 | 38.1 | 55.6 | 87.8 | 19.1 | 6.6 | 25.4 | 22.2 | 43.5 | 11 | 5560 |
| C220AS C220AL |
63.5 | 19.05 39.68 |
4 | 23.8 | 47.1 | 66.6 | 107.4 | 23.4 | 9.2 | 31.8 | 28.6 | 53.5 | 13 | 8670 |
| C224AS C224AL |
76.2 | 22.23 44.45 |
4.8 | 28.6 | 47.6 | 79.3 | 128.8 | 27.8 | 11 | 37.3 | 33.3 | 63.0 | 15 | 12460 |
| C100AS C100AM C100AL |
100 |
19.05 30 40 |
3.2 3.2 4.5 |
40 |
65 |
60 60 70 |
92 92 113 |
15 15 22 |
10 | — | — | — | — | 2940 6860 |
